Concrete conveyor belt TD16.5 Theme

Manufacturer: Theam (France)
Additional services:

Telescopic conveyor belt for concrete TD16.5 Theam - 16.5 meters steel

Conveyor (conveyor) belt for concrete TD16.5 Theam - steel telescopic structure, transporting concrete to a distance of 16.7 meters. It has two telescopic elements 3.8 m and 1.2 m long. This gives increased flexibility and maximum coverage.

Concrete conveyor belt TD16.5 - THEAM (France)

• Transportation distance: 10.7 to 16.7 m
• Telescope - 2nd element: 3.8 m
• Telescope - 3rd element: 1.2 m
• Tape width: 360 mm
• Productivity: 70 m3/h
• Rotation angle: 310°
• Weight: 3250 kg
• Max. dumping height: 9.5 m
• Steel construction
• Stabilizers
• One lateral extendable support
Concrete conveyor belt TD16.5 Theam
- Increased Flexibility, Maximum Coverage
Two telescopes (3.8 m in the 2nd section and 1.2 m in the 3rd section) make it possible to reach a maximum of 16.7 m.
And reach a maximum discharge height of 9.5 m.
Concrete conveyor belt TD16.5 is ideal for delivering concrete to the first or second floor.

- Quality of transportation
Proportional sensitive controls for greater delivery accuracy.
A sliding system prevents the segregation of concrete and is compatible with any kind of plasticity of concrete.

- Additional options
Controlling the conveyor using a remote control.
Raise the conveyor UP/Down using the remote control.
High voltage line detector.
High pressure washer.
Collapsible system.

The conveyor belt for concrete TD16.5, thanks to two telescopic sections, has a maximum coverage of 16.7 m. It can transport concrete to the second floor. It has a convenient and sensitive radio control.
